Raytac AN54LV-15 nRF54L15 Module Chip Antenna Nordic Bluetooth | Shop The World
From USA
NewRaytac
Raytac AN54LV-15 nRF54L15 Module Chip Antenna Nordic Bluetooth BT6 FCC IC CE Telec KC RCM SRRC
ℹ
Products from the USA may come with an input voltage of 110V–120V, requiring a step-down transformer. Check the device wattage to select the correct power converter.
•Bluetooth 6 and Channel Sounding Support: Features BT6 specification with Channel Sounding capability, pre-certified with FCC, IC, CE, Telec, KC, SRRC, and NCC regulatory approvals
•Nordic Semiconductor Recommended Module: A recommended third-party module by Nordic Semiconductor ensuring quality and compatibility with Nordic development ecosystem
•Compact Form Factor: Ultra-compact dimensions of 6.4 x 8.4 x 1.5 mm (0.25 x 0.33 x 0.05 inches) with integrated chip antenna for space-constrained designs
•Extensive GPIO Capability: Features 32 general-purpose input/output pins with embedded chip antenna for comprehensive connectivity and control options
•Wide Operating Temperature Range: Operates reliably in extreme conditions from -40 to +105C, suitable for industrial and automotive applications
•Comprehensive Interface Support: Includes QSPI, SPI, UART, I2C, I2S, PDM, PWM, ADC, and NFC interfaces for versatile peripheral connectivity
•Interfaces: QSPI, SPI, UART, I2C, I2S,PDM, PWM, ADC, and NFC
