REES52 2 Pack SG90 Micro Servo Motor 9G Mini Servo Kit for RC Robot Arm/Hand/Control with Cable (Control Angle 360 Degree)
•Interface Type: Compatible with JR & Futaba interface. Micro servo running speed (at no load) : 0.09±0.01 sec/60 degree (4.8V) 0.08 ± 0.01 sec/60 degree(6V). Running angle: 180 degree.
•SG90 9G micro servo motor for remote control helicopters, micro robot, robot arm and boats. Fit for ALL kinds of RC Toys and also make electronics DIY compatible with Arduino, Raspberry Pi.
•Stall Torque (4.8V): 1.6kg/cm; Operating voltage: 4.2V~ 6V; Temperature range: 0 to 55; Operating Speed: 0.1sec/60degree; Dead band width: 10usec.
•The SG90 has 3 wire interfaces in which the connections should be made as follows: Red wire-5V, Brown Wire-Ground, Yellow wire-digital pin 9.
•Mini servo SG90 is tiny and lightweight with high output power.
