Premium Mini Snap Swch, 3A, SPNC, Pin Plngr

ℹ

Products from the USA may come with an input voltage of 110V–120V, requiring a step-down transformer. Check the device wattage to select the correct power converter.

•Price For: Each Series: V-Basic Mounting Dimension - Snap Action Switch: 0.87" Centers Electrical Connection - Snap Action Switch: Quick Connect Watertight - Snap Action Switch: No Height - Snap Action Switch: 0.63" Number of Circuits - Snap Action Switch: 1 Depth - Snap Action Switch: 0.40" Width - Snap Action Switch: 1.14" Housing Material: PCT Polyester Thermoplastic
•Item: Miniature Snap Action Switch Snap Action Switch Type: Miniature Snap Action Switch AC Contact Rating - Snap Action Switch: 3A @ 240V Operating Force: 1.47N Contact Form- Switches: 1NC Lever Actuator Length - Snap Action Switch: Not Applicable Actuator Type - Snap Action Switch: Plunger, Pin Basic Actuator Type - Snap Action Switch: Plunger Over Travel: 1.27mm Differential Travel: 0.01" Release Force: 0.86 oz.
•Max. Pretravel: 1.19mm Standards: UL, CSA, ENEC Operating Temp. Range: -40 Degrees to 180 Degrees F Country of Origin (subject to change): Mexico

Premium Mini Snap Swch, 3A, SPNC, Pin Plngr

Premium Mini Snap Swch, 3A, SPNC, Pin Plngr
