Poynting Puck 5-in-1 Transportation, IOT, M2M Antenna - Black - SMA - Thread Mount

ℹ

Products from the USA may come with an input voltage of 110V–120V, requiring a step-down transformer. Check the device wattage to select the correct power converter.

•698 - 3800 MHz; 2X2 LTE (MIMO), 6 dBi; 2X2 Wi-Fi (MIMO), 7.5 dBi; GPS/GLONASS, 21 dBi
•Poynting Part # A-PUCK-0005-V1-B is 5G Ready; includes 3.2GHz to 3.8GHz CBRS Band
•Gain (max) Port 1 & 2: -1dBi @ 698-960 MHz, 6dBi @ 1710-2700 MHz, 6dBi @ 3200-3800 MHz / Wi-Fi: 5dBi @ 2400-2500 MHz and 7.5dBi @ 5000–6000 MHz
•The antenna provides two separate dual-band Wi-Fi antennas offering concurrent 2.4GHz and 5 GHz bands, capable of 802.11n and 802.11ac/ax with 2x2 MIMO
•Coax Cable Type RTK-031, Cable Length: 2m (6.5ft), Connectors: SMA (male)
•Robust, vandal resistant and design provides ruggedness, corrosion, water, dust resistance (IP68)
•Ideal for Smart Utilities, digital signage, transportation, marine and IoT/M2M use
•Poynting Part # A-PUCK-0005-V1-B

From USA

NewPOYNTING ANTENNAS (PTY) LTD.

Poynting Puck 5-in-1 Transportation, IOT, M2M Antenna - Black - SMA - Thread Mount

ℹ

Products from the USA may come with an input voltage of 110V–120V, requiring a step-down transformer. Check the device wattage to select the correct power converter.

•698 - 3800 MHz; 2X2 LTE (MIMO), 6 dBi; 2X2 Wi-Fi (MIMO), 7.5 dBi; GPS/GLONASS, 21 dBi
•Poynting Part # A-PUCK-0005-V1-B is 5G Ready; includes 3.2GHz to 3.8GHz CBRS Band
•Gain (max) Port 1 & 2: -1dBi @ 698-960 MHz, 6dBi @ 1710-2700 MHz, 6dBi @ 3200-3800 MHz / Wi-Fi: 5dBi @ 2400-2500 MHz and 7.5dBi @ 5000–6000 MHz
•The antenna provides two separate dual-band Wi-Fi antennas offering concurrent 2.4GHz and 5 GHz bands, capable of 802.11n and 802.11ac/ax with 2x2 MIMO
•Coax Cable Type RTK-031, Cable Length: 2m (6.5ft), Connectors: SMA (male)
•Robust, vandal resistant and design provides ruggedness, corrosion, water, dust resistance (IP68)
•Ideal for Smart Utilities, digital signage, transportation, marine and IoT/M2M use
•Poynting Part # A-PUCK-0005-V1-B
