flagProduct From USA
new | XICOOLEE Microwave Radar Sensor Module LD2410, 24GHz ISM Band, Human Presence Motion Sensing Module, Non-Contact Monitoring Detector, Horizontal Connect, with Bluetooth, Support GPIO and UART Output
Brand : xicoolee
new | XICOOLEE Microwave Radar Sensor Module LD2410, 24GHz ISM Band, Human Presence Motion Sensing Module, Non-Contact Monitoring Detector, Horizontal Connect, with Bluetooth, Support GPIO and UART Output
Brand : xicoolee

*Prices subject to change due to market. The price shown in the checkout is the guaranteed price.
₹ 2,875.00
M.R.P :₹ 4,024.00

5% OFF

Availability :
In Stock

*Prices subject to change due to market. The price shown in the checkout is the guaranteed price.
₹ 2,875.00
M.R.P : ₹ 4,024.00

5% OFF

Availability :
In Stock
Delivery :
Available This pincode is not serviceable! Please try with a different pincode Checking...
Quantity
7 days Replacement
7 days Replacement
Manufacturers Warranty
Manufacturers Warranty
Top Brand
Top Brand
Free delivery
Free delivery
Secure Transaction
Secure Transaction
Blue Dart Delivered
Blue Dart Delivered
Contact For Bulk Product Enquiry
100% Guarantee Safe Checkout
  • visa
  • mastercard
  • discover
  • Maestrocard
  • paypal
  • americanexpress
  • paytm
  • upi
Note: Please be aware that products from the USA may come with an input voltage of 110V - 120V, requiring the use of an appropriate step-down transformer for compatibility. Understanding the device's wattage is essential for selecting the correct power converter.
Product Specifications
Conditionnew
AsinB0BJ8CWWS9
CategoryElectronics
SubcategorySingle Board Computers
LeafcategoryMOTION_DETECTOR_DEVICE
MPNsensing module LD2410
ColorLD2410-Sensor Module(Horizontal)
OriginUSA
Brandnamexicoolee
Length1.37795
Width0.27559
Weight1
Product Details
1.It can sensitively sense static, micro moving, sitting and lying human bodies that cannot be identified by traditional solutions
2.It is plug and play and easy to assemble; Small and simple, the minimum size is only 7mmx35mm, and equipped with Bluetooth
3.The farthest sensing distance is up to 5 meters; Support ceiling, wall and otherinstallation methods
4.Accurately identify withinthe interval, supportthedivision ofthe sensing range, andshield the interferenceoutside the interval
5.Multi-level intelligent parameter adjustmentto meetthe needs of scene changes
Product Ranking
#1458 in Motion Detectors (Electronics)
#559269 in Electronics
Product Description
Overview

LD2410 is a high-sensitivity 24GHz human presence status sensing module developed by Hilink Electronics.
Its working principle is to use FMCW frequency-modulated continuous wave to detect human targets in the set space.

Application scenarios

1. Human body sensor light control
It senses whether there is someone in the space, and automatically controls lights,
suchas lighting equipment in public places, various sensor lights, bulb lights, etc.
2.Human body induction wake-up of advertising screens and other devices
Automatically turn on when people come, and automatically sleep when no one comesto save power,
information delivery is more accurate and efficient
3. life safety protection
UV lamp work protection to prevent the UV lamp from being turned on when there are people around and causing personal injury Automatic detection
and alarming of dangerousplaces to prevent people from entering specific high-risk spaces,
such as high-risk placeswhere coal mine blasting personnel enter.
4. Smart Appliances
When there is no one in the room for a long time, the TV, air conditioner and otherelectrical appliances are automatically turned off, saving energy and safety
5. Smart Security
Detection and identification of people intruding, staying, etc. within the specified range

Specifications

Dimensions: 35mm(length)*7mm(Width)
Interface: 1 GPIO，IO level 3.3V，1 UART
Power Requirements: DC 5V，Power supply capability>200mA
Average operating current: 80 mA
Detection distance: 0.75m～6m,adjustable
Working frequency: 24GHz~24.25GHz,Compliant with FCC, CE, non-commission certification
Modulation: FMCW
Detection angle: ±60 °
Distance resolution: 0.75m
Sweep Bandwidth: 250MHz ,Compliant with FCC, CE, non-commission certification
Ambient temperature: -40 ~ 85℃

Package contents
1.MX1.27 5Pin Header x1
