new | 6pcs I2C Display Module 0.91 Inch I2C OLED Display Module I2C OLED Screen Driver DC 3.3V~5V for Raspberry pi ESP32 ESP8266 AVR/PIC/STM32
Brand : Coliao
new | 6pcs I2C Display Module 0.91 Inch I2C OLED Display Module I2C OLED Screen Driver DC 3.3V~5V for Raspberry pi ESP32 ESP8266 AVR/PIC/STM32
Brand : Coliao

*Prices subject to change due to market. The price shown in the checkout is the guaranteed price.
₹ 4,006.00
M.R.P :₹ 5,608.00

5% OFF

Availability :
In Stock

*Prices subject to change due to market. The price shown in the checkout is the guaranteed price.
₹ 4,006.00
M.R.P : ₹ 5,608.00

5% OFF

Availability :
In Stock
Delivery :
Available This pincode is not serviceable! Please try with a different pincode Checking...
Quantity
7 days Replacement
7 days Replacement
Manufacturers Warranty
Manufacturers Warranty
Top Brand
Top Brand
Free delivery
Free delivery
Secure Transaction
Secure Transaction
Blue Dart Delivered
Blue Dart Delivered
Contact For Bulk Product Enquiry
100% Guarantee Safe Checkout
  • visa
  • mastercard
  • discover
  • Maestrocard
  • paypal
  • americanexpress
  • paytm
  • upi
Note: Please be aware that products from the USA may come with an input voltage of 110V - 120V, requiring the use of an appropriate step-down transformer for compatibility. Understanding the device's wattage is essential for selecting the correct power converter.
Product Specifications
Conditionnew
AsinB09YY4RD26
CategoryElectronics
SubcategorySingle Board Computers
LeafcategoryELECTRONIC_COMPONENT
MPNColiao-I2C OLED Display Module
ColorWhite Display
OriginUSA
BrandnameColiao
Weight1
Product Details
0.91 Inch I2C OLED Display: Resolution is 128*32, no need backlight, self-illumination. These I2C OLED display module comes with pin headers, you don't need buy it separately.
The main chip is SSD1306; supports DC 3.3V to 5.0V supply. Working Temperature: -30 degrees ~ 70 degrees.
Power-saving Display: The I2C OLED display performs better than the traditional LCD display and with lower consumption the IIC (I2C communications) simplifies connections.
With chip select CS signal, you can achieve multiple IIC device on the same bus work,compatible with 3.3V and 5V control chip I / O level.
Well Compatibility: This I2C OLED display module can be used for ESP8266, ESP32, STM32, ARM etc.
Product Ranking
#6856 in Single Board Computers (Computers & Accessories)
Product Description
I2C display module 0.91 inch I2C OLED display module I2C OLED screen driver dc 3.3V - 5V

These I2C OLED display module comes with pin headers, you don't need buy it separately.
It can be used for PIC/AVR/ESP32/ESP8266/ARM etc.
The I2C OLED display performs better than the traditional LCD display and with lower consumption the IIC (I2C communications) simplifies connections.

Note:
Do not reverse VCC and GND. This will cause damage to the OLED display.

Pin Description:
GND: Power Ground
VCC: Power + (DC 3.3 ~5v)
SCL: Clock Line
SDA: Data Line

Specification:
Model: SH-S091
Screen size: 0.91 inch
Interface: IIC
The main chip is: SSD1306
Operating voltage: supports DC 3.3V~5.0V power supply.
Working Temperature: -30 degrees ~ 70 degrees
Display area: 22.384 x 5.584 (mm)
Interface Type: IIC Interface
Number of Pins: 4Pin
Material:PCB
Size:38x12mm

Package Including:
6 * 0.91 Inch I2C SSD1306 OLED Display Module
