Shifting between the refrigerating and heating modes
One-way 10K NTC temperature sensor input
new | Thermostat, Set Key Practical Thermostat with Sensor, One-way Reliable Led for Temperature Deviation Refrigerating And Heating Situations
Brand : Voluxe
new | Thermostat, Set Key Practical Thermostat with Sensor, One-way Reliable Led for Temperature Deviation Refrigerating And Heating Situations
Brand : Voluxe
Availability :
Out Of Stock
Click to connect with our customer support
Product Specifications
| Condition | new |
|---|---|
| Asin | B0912VF5NW |
| Category | Industrial & Scientific |
| Subcategory | Temperature Controllers |
| Leafcategory | Home Improvement |
| MPN | Voluxehvmggyeuaf |
| Origin | USA |
| Brandname | Voluxe |
| Height | 1 |
| Length | 1 |
| Width | 1 |
| Weight | 1 |
Product Details
Temperature display
Delay protection of compressor
One-way NO & NC output
What's Inside The Box ?
inc
Product Description
Product function introduction:
The one-way temperature controller can set as refrigerating or heating, using 10K general NTC thermistor to control temperature, control the one-way relay (NO, NC) output. The temperature range controlled is -45℃-110℃. It is used extensively in various refrigerating and heating situations.
Under refrigerating mode, the output opens when the temperature is above (temperature control value + backlash), and stops when temperature is the at temperature control value.
Under heating mode, the output opens when the temperature is below (temperature control value - backlash), and stops when temperature is the at temperature control value.
The temperature control value and backlash are adjustable. Correction function for temperature deviation is also available.
DIN rail-type installation is adopted which is easy and fast for installing.
The advanced design of isolating power supply is adopted, which can ensure the controller work steadily, reliably, and continuously when the power supply changes between 100V and 240VADC.
Main Features:
One-way 10K NTC temperature sensor input One-way NO & NC output Temperature display Shifting between the refrigerating and heating modes Delay protection of compressor Correction of measured temperature deviation Power-down memory protection functionPanel introduction
1.T
Product Description
Product function introduction:
The one-way temperature controller can set as refrigerating or heating, using 10K general NTC thermistor to control temperature, control the one-way relay (NO, NC) output. The temperature range controlled is -45℃-110℃. It is used extensively in various refrigerating and heating situations.
Under refrigerating mode, the output opens when the temperature is above (temperature control value + backlash), and stops when temperature is the at temperature control value.
Under heating mode, the output opens when the temperature is below (temperature control value - backlash), and stops when temperature is the at temperature control value.
The temperature control value and backlash are adjustable. Correction function for temperature deviation is also available.
DIN rail-type installation is adopted which is easy and fast for installing.
The advanced design of isolating power supply is adopted, which can ensure the controller work steadily, reliably, and continuously when the power supply changes between 100V and 240VADC.
Main Features:
One-way 10K NTC temperature sensor input One-way NO & NC output Temperature display Shifting between the refrigerating and heating modes Delay protection of compressor Correction of measured temperature deviation Power-down memory protection functionPanel introduction
1.T
