flagProduct From USA
new | Taidacent RS485 TTL DS18B20 Temperature Sensor Modbus RTU Programmable Serial Port Remote Control Acquisition Module for Arduino PC PLC MCU (5V TTL with Sensor)
SKU : 06606BAUXXB089KLRQGR
Brand : Taidacent
new | Taidacent RS485 TTL DS18B20 Temperature Sensor Modbus RTU Programmable Serial Port Remote Control Acquisition Module for Arduino PC PLC MCU (5V TTL with Sensor)
SKU : 06606BAUXXB089KLRQGR
Brand : Taidacent
Product Specifications
Conditionnew
AsinB089KLRQGR
CategoryIndustrial & Scientific
SubcategoryTemperature Probes & Sensors
LeafcategoryBISS Basic
MPNZC-RS485TTLDS18B20temsensor-0602
OriginUSA
BrandnameTaidacent
Height1
Length1
Width1
Weight6
Product Details
Using DS18B20 temperature and humidity sensor
MODBUS RTU protocol, 03 read command, 06 write command.
Serial port baud rate: 9600 (default), N, 8, 1
By modifying the 485 address, up to 247 modules can be used in cascade (more than 16 please use R485 repeater)
The temperature measurement range is: -55°C to +125°C (-67°F to +257°F)
Product Ranking
#5509 in Temperature Probes & Sensors
#1617020 in Industrial & Scientific
Product Description
Function description:
Power supply voltage: A/B 5V version: DC 3.7-5.5V; C 12V version: 6-25V
Working current: 5-8MA
NO means without DS18B20 temperature sensor, TS means with DS18B20 temperature sensor
A means 5V version TTL232 interface, B means 5V version RS485 interface, C means 12V version RS485 interface
MODBUS RTU protocol, 03 read command, 06 write command.
Serial port baud rate: 9600 (default), N, 8, 1
By modifying the 485 address, up to 247 modules can be used in cascade (more than 16 please use R485 repeater)
Using DS18B20 temperature and humidity sensor
The temperature measurement range is: -55°C to +125°C (-67°F to +257°F).
It has an accuracy of +-0.5℃ when the temperature is within -10℃ to 85℃.
Size: A/B version 30 X 15 X 3.5MM, C version 30 X 15 X 6MM
Weight: 1.4-1.9 g without sensor, 1.9-2.2 g with sensor
Typical application:
Thermostatic Controls
Industrial Systems
Consumer Products
Thermometers
Thermally Sensitive Systems
Indoor and outdoor temperature measurement
Temperature in vegetable garden
Weather forecasting, and monitoring
Temperature in Computer Room
Warehouse temperature
Product Description
Function description:
Power supply voltage: A/B 5V version: DC 3.7-5.5V; C 12V version: 6-25V
Working current: 5-8MA
NO means without DS18B20 temperature sensor, TS means with DS18B20 temperature sensor
A means 5V version TTL232 interface, B means 5V version RS485 interface, C means 12V version RS485 interface
MODBUS RTU protocol, 03 read command, 06 write command.
Serial port baud rate: 9600 (default), N, 8, 1
By modifying the 485 address, up to 247 modules can be used in cascade (more than 16 please use R485 repeater)
Using DS18B20 temperature and humidity sensor
The temperature measurement range is: -55°C to +125°C (-67°F to +257°F).
It has an accuracy of +-0.5℃ when the temperature is within -10℃ to 85℃.
Size: A/B version 30 X 15 X 3.5MM, C version 30 X 15 X 6MM
Weight: 1.4-1.9 g without sensor, 1.9-2.2 g with sensor
Typical application:
Thermostatic Controls
Industrial Systems
Consumer Products
Thermometers
Thermally Sensitive Systems
Indoor and outdoor temperature measurement
Temperature in vegetable garden
Weather forecasting, and monitoring
Temperature in Computer Room
Warehouse temperature
