new | Gigabit PoE Extender - 1 in 2 Out, PoE+ 60W, IEEE 802.3af/at Repeater, Lightning Protection
Brand : UltraPoE
new | Gigabit PoE Extender - 1 in 2 Out, PoE+ 60W, IEEE 802.3af/at Repeater, Lightning Protection
Brand : UltraPoE
Availability :
Out Of Stock
Click to connect with our customer support
Product Specifications
Condition
New
Asin
B07RQ6RLTC
Category
Electronics
Subcategory
Switches
Leafcategory
ELECTRONIC_SWITCH
MPN
PoE-2003-2P
Color
PoE-EX2003-60W
Origin
USA
Brandname
UltraPoE
Height
1.1
Length
4.72
Width
3.34
Weight
1
Warranty Description
one year warranty and free lifetime tech support
Product Details
Converts a non-PoE Gigabit port to a PoE / PoE+ Gigabit port ,and Extends the range of PoE and Ethernet an additional 100 meters (328 ft.) away
Gigabit PoE extender no additional power supply is required，This PoE extender has built-in 6 KV lightning protection
With Auto-sensing technology , Automatically detects and protects PoE equipments from being damaged by incorrect installation
Full-rate network throughout the whole extended distance
3 Ethernet ports, 2 port PoE with 60W total power budget, 1 port uplink . Wall-Mountabl e design,Easy plug-and-play installation
What's Inside The Box ?
Instruction manual
Product Ranking
#957 in Repeaters
Product Description
About PoE Extender
Ethernet and PoE connections both restrict cable distances to 100 meters between network ports. To overcome this distance limit, network installers can simply connect an PoE Extender in-line with the Cat-5e or Cat-6 calbe.
With Gigabt PoE Extender, PDs (such as IP Security Cameras, VoIP telephones, wireless access points) can be installed at greater distances than 100 meters from one another. By connecting PoE Extender for every extra 100 meters of cable, both Ethernet and PoE can be extended to 200 meters, 300 meters, or even greater distances, depending on PDs power required and power source.
Description
No. of channels:1(PoE IN) into 2(PoE OUT)
Pass Through Data Rates: 10/100/1000 Mbps half/full duplex
Output Power: up to 22W
Indicators: LED indicators are located on the RJ45 connector
Power indicator: PoE enabled
Network indicator: Link/Act
Connectors: Shielded RJ-45, EIA 568A and 568B
Network cables: Shielded category 5 (or higher)
Dimensions:119mm x 85mm x 28mm
Mounting: Wall of shelf
Environment: Indoor or Outdoor
Operating Ambient Temperature: -10 to 45℃
Operating Humidity: Maximum 90%, Non-condensing
Storage Temperature: -30 to 70℃
Storage Humidity: Maximum 95%, Non-condensing
Regulatory Compliance: IEEE 802.3af (PoE), IEEE 802.3at (PoE+)
EMI standards complies with FCC, CE cl
