new | ImmersionRC SpiroNet 13dbi Large Patch Antenna 5.8GHz RHCP
Brand : ImmersionRC
new | ImmersionRC SpiroNet 13dbi Large Patch Antenna 5.8GHz RHCP
Brand : ImmersionRC

*Prices subject to change due to market. The price shown in the checkout is the guaranteed price.
₹ 11,319.00
M.R.P :₹ 15,846.00

5% OFF

Availability :
In Stock

*Prices subject to change due to market. The price shown in the checkout is the guaranteed price.
₹ 11,319.00
M.R.P : ₹ 15,846.00

5% OFF

Availability :
In Stock
Delivery :
Available This pincode is not serviceable! Please try with a different pincode Checking...
Quantity
7 days Replacement
7 days Replacement
Manufacturers Warranty
Manufacturers Warranty
Top Brand
Top Brand
Free delivery
Free delivery
Secure Transaction
Secure Transaction
Blue Dart Delivered
Blue Dart Delivered
Contact For Bulk Product Enquiry
100% Guarantee Safe Checkout
  • visa
  • mastercard
  • discover
  • Maestrocard
  • paypal
  • americanexpress
  • paytm
  • upi
Note: Please be aware that products from the USA may come with an input voltage of 110V - 120V, requiring the use of an appropriate step-down transformer for compatibility. Understanding the device's wattage is essential for selecting the correct power converter.
Product Specifications
Conditionnew
AsinB01A7XPZW2
CategoryElectronics
SubcategoryNetwork Antennas
LeafcategoryPersonal Computer
MPN58
OriginUSA
BrandnameImmersionRC
Height1
Length1
Width1
Weight1
Product Details
13dBi Right-Hand (RHCP) Circular Polarized Patch antenna, Full-Custom design for the FPV market.
Ideal companion to our 5.8GHz SpiroNET Omnidirectional CP antennas, ranges of several km on a CE-legal 25mW system very possible!
Made by ImmersionRC
Product Description
This 5.8GHz Right-Hand (RHCP) Circular Polarized patch antenna was custom-designed, with no expense spared, for the FPV market. Light enough to be mounted directly onto an LCD headset, or directly onto the front of one of our Uno, or Duo receivers. This antenna will breathe new life into the CE-Legal 25mW systems, allowing multi-km range with ease. For 600mW systems, its time to start worrying about the range of the control link, since with a combination of this antenna, and a spiroNET omni, the video range can greatly exceed the control range of most 2.4GHz radios. Precision manufactured with very tight tolerances, *each antenna* is 100% tested on a professional antenna tester (Rhode & Schwartz) to ensure maximum range and performance. SMA male connector compatible with all FatShark/ImmersionRC 5.8GHz products sold to date. Right-Hand circular polarization 5.8GHz ISM Band 13dBi gain Beam width 35 degrees (H + V) F/B Ratio 26dB VSWR < 1.5:1 (5740 - 5860MHz) Impedance 50ohms
