MACHINIST MR9A Mainboard X99 Motherboard LGA 2011-3 Support Xeon E5 2667 2666 V3 V4 Series CPU Processor DDR4 ECC RAM NVME M.2 SATA 3.0 ATX MR9A Mainboard
Features:
Support SATA 3.0, 2Pcs NVME M.2
Supports DDR4 ECC server memory and DDR4 desktop memory
8-phase power supply, VRM does not need a radiator, overclocking will not heat
All solid-state capacitors, fine workmanship, professional and stable.
Brand Name: MACHINIST
Chipset Manufacturer: Intel
Chipset: Intel B85
Max LAN Speed: 1000Mbps
Quality Certification: CE,ROHS
Form Factor: ATX
Size: 28x21.5cm
Support Memory Type: DDR4 / DDR4 ECC
Maximum Ram Capacity: 128 GB
Storage Interface Type: SATA 3,M.2 (NVMe)
Number of M.2: 2
Onboard LAN: 1x RJ45
With CPU: No
Back I/O Ports: 1x RJ45, 2xPS/2 ,3 x Audio Jacks
Socket Type: LGA 2011-3
Number Of Memory Slots: 4
Support USB Type: USB 2.0,USB 3.0
PCI - E standards: PCI - E 3.0
Number of PCIe x 1: 1
Number of PCIe x 4: 1
Number of PCIe x 8: 0
Number of PCIe x 16: 2
Number of SATA Ports: 6
MACHINIST: X99 Motherboard, X99 LGA 2011-3 Motherboard
Usage Scenario: Enthusiast & Overclocking, Gaming, Audio & Video, Household, Office, Design, Video, Desktop, Server, Workstation, Mining, Production, Workstation, Scientific Computing, 3-D Modeling, Video Rendering, MaxCompute, Others, HPC
Origin: Mainland China
Item Specification:
Brand: Machinsit
Condition: Brand New
CPU socket: LGA 2011-3
Motherboard model: X99 MR9A
Structure: ATX
Chipset: Intel B85
Memory slot: 4*DDR4 (four memory channels)
Maximum memory supported: 128GB = 4*32GB DDR4
Supported memory types: The memory types support DDR4 desktop and server memory. (Please use Samsung, Kingston, SanDisk, Micron, Hynix and other international brands, other brands are not compatible)
Ethernet port: 10/100/1000Mbps/s
Video output port: requires graphics card support
Interface: 1*RJ45/1*PS2/4*SATA2.0/2 *SATA3.0/6*USB2.0/2*USB3.0/2*PCI-E x16/1*PCI-E x1/1* PCI-E x4/1*NVME/NGFF M.2 interface;
Motherboard size: 215MM*280MM
Motherboard weight (including packaging): about 1.2kg.
Application: Desktop, Server, Workstation, Mining
Usage Scenario: Enthusiast & Overclocking, Gaming, Audio & Video, Household, Office, Design, Video Production, Server, Others
Packing List:
1 * X99 E5 MR9A Mainboard X99 LGA 2011-3 Motherboard
1 * CPU Cooling Bracket
1 * I/O Shield
1 * Sata Cable
Notes:
1: The color of the slot bottom plate may vary from batch to batch, but it will not affect the use of the product. Products are continuously optimized and upgraded.
2: Please allow 1-3mm difference due to manual measurement.
3: Due to different monitors and different light, the pictures may not show the actual color of the goods. Thanks for your understanding.
4: This floor plan requires a strong power supply. Make sure your power supply is sufficient for this scenario. (at least 500w brand power supply)
5: The battery in the photo of the motherboard will be taken out before shipping, because China Post and Customs prohibit the use of batteries.
