This item is brand-new, factory sealed.

The Club 3D CSV-1566 USB Gen1 Type-C Triple Display DP™ Alt mode + Displaylink™/ USB mode™ Dynamic PD Charging Dock with 120 Watt PS, is an integrated solution combining Video, Data, Power, Ethernet and Audio. This Dock is perfectly suited for extending a Type-C port or USB-A port(via a Type-C to USB converter) to provide multiple audio,video, data and power ports, providing an ideal solution to satisfy users who require multiple ports. This dock has 3 video ports (2 HDMI™, one from DP™1.2 Alt mode, one from USB mode, 1 Displayport™ from USB mode) for video experience, 4 USB Gen1 Type-A and 1 USB Gen1 Type-C for data transmission, RJ45 for super high speed Ethernet, SD/TF card slots for connecting memory cards. Besides, it has a smart charging port, bringing fast charging performance for connected mobile device(Apple,samsung phones, pads,etc). A 120W power adapter is provided to supply power for the function of this dock and charge the host with max 80W (20V/4A). This dock is a bottom design with can be put underneath the host. It can work on DP™1.2 Alt mode supported USB Type-C and -A hosts.

Features:

• Support DP1.2 Alt mode and Displaylink™/ USB mode
• Designed for extending USB Type-C port or -A port (by connecting a Type-C to USB-A converter)to be multiple video,data and power ports
• Allow to output triple videos(dual 4K/60Hz+4K/30Hz) to work simultaneously with MST under both Mac and window system
• HDMI™ 1 (DP™ Alt mode) supports max 4K/30Hz
• HDMI™ 2 (USB mode) supports max 4K/60Hz
• DP™(USB mode) support max 4K/60Hz
• Support DP++
• Support smart charging with max 5V/2.4A
• Support Gigabit Ethernet to get access to super fast network
• Support UHS-I SD3.0 with max 104Mbps, allow 2 card slots to work simultaneously
• Support audio in and out
• Support max 120W DC power in and bypass 80W to host
• Short-circuit, over-current, over-voltage protection

• CSV-1566 Docking Station
• PowerSupply
• Plugs
• USB Gen2 Type-C Cable 10G, 20V5A M/M, 1 m / 3.28 ft
• Quick Install Guide
