new | LuatOS 3 PCS USB C ESP32 S3 Development Board, ESP32-S3 MCU with 8MB PSRAM, 16MB Flash and 512K SRAM, ESP32 Board with WiFi, Bluetooth, On-Board CH343P and Rich Interfaces, Arduino IDE Compatible
Brand : LuatOS
new | LuatOS 3 PCS USB C ESP32 S3 Development Board, ESP32-S3 MCU with 8MB PSRAM, 16MB Flash and 512K SRAM, ESP32 Board with WiFi, Bluetooth, On-Board CH343P and Rich Interfaces, Arduino IDE Compatible
Brand : LuatOS
Availability :
Out Of Stock
Click to connect with our customer support
Product Specifications
Condition
New
Asin
B0CDX87YX4
Category
Electronics
Subcategory
Single Board Computers
Leafcategory
SINGLE_BOARD_COMPUTER
MPN
ESP32S3-3PCS
Color
blue
CPU Manufacturer
Espressif
CPU Speed
240
Processor Count
3
Origin
USA
Brandname
LuatOS
Height
0.16
Length
2.01
Width
0.83
Weight
1
Warranty Description
2 Years
Product Details
Powerful Performance Setup: Featuring 8MB PSRAM, 16MB FLASH and 240MHz clock frequency, providing abundant memory and storage for applications, supporting intricate software and data processing, enhancing project efficiency.
Extensive Interface Variety: ESP32-S3 offers a wide array of interfaces, such as UART, GPIO, SPI, I2C, ADC, PWM, SDIO, and Camera, ensuring versatile connectivity and expansion choices to suit diverse project requirements.
Seamless Wireless Connectivity: Built-in 2.4G antenna supports WiFi and Bluetooth, ensuring stable wireless links for devices, ideal for IoT, smart homes, and various applications.
Easy Debugging & Development: CH343P USB-to-Serial chip streamlines downloads and flashing, with an analog switch for seamless transition to ESP32S3's built-in USB interface, ensuring smooth USB functionality development and debugging.
Adaptable Usage: Our ESP32 Arduino compatible board adopts unique stamp hole design enables versatile scenarios, enhancing project flexibility from prototyping to production stages.
What's Inside The Box ?
3 X ESP32-S3 Development Boards
Product Ranking
#4670 in Single Board Computers (Computers & Accessories)
Product Description
Unleash the power of practicality and versatility with our cutting-edge design, built upon the ESP32-S3 by Espressif. Elevate your projects to new heights with CORE_ESP32_S3. Transform your ideas into reality with ease and precision. Explore the endless horizons of innovation today!
Interfaces Instruction
- 4 SPI interfaces
- 1 LCD interface, supporting 8 to 16-bit parallel RGB, I8080, MOTO6800 protocols, and conversion between RGB565, YUV422, YUV420, YUV411
- 1 DVP 8 to 16-bit camera interface
- 3 UART serial interfaces
- 2 I2C interfaces
- 2 I2S interfaces
- 1 RMT (TX/RX) interface
- 1 pulse counter for LED PWM control, supporting up to 8 channels
- 1 full-speed USB OTG interface
- 1 USB serial/JTAG controller interface
- 2 MCPWM interfaces
- 1 SDIO host interface with 2 slots
- General DMA controller (GDMA) with 5 receive and 5 transmit channels
- 1 TWAI controller, compatible with ISO 11898-1 (CAN 2.0 specification)
- 2 12-bit SAR ADCs, supporting up to 20 channels
NOTE: Any GPIO can be used as PWM or ADC pin, and the numbering is consistent with GPIO. However, only up to 8 PWM channels can be enabled at the same time, so please be careful.
Board Parameter
- Size: 0.83 inches*2.01 inches
- SRAM: 512KB
- PSRAM: 8MB
- FLASH: 16MB
- WIFI IEEE: 802.11b/g/n
- Bluetooth BLE 5.0 & mesh
- Chip: ESP32-WROOM-32; Onboard CH343P USB to serial chip
- Connection: USB Type C
Shipping List
- 3 X ESP32-S3 Development Boards
- 6 X 16-PIN Headers
Product Description
Unleash the power of practicality and versatility with our cutting-edge design, built upon the ESP32-S3 by Espressif. Elevate your projects to new heights with CORE_ESP32_S3. Transform your ideas into reality with ease and precision. Explore the endless horizons of innovation today!
Interfaces Instruction
- 4 SPI interfaces
- 1 LCD interface, supporting 8 to 16-bit parallel RGB, I8080, MOTO6800 protocols, and conversion between RGB565, YUV422, YUV420, YUV411
- 1 DVP 8 to 16-bit camera interface
- 3 UART serial interfaces
- 2 I2C interfaces
- 2 I2S interfaces
- 1 RMT (TX/RX) interface
- 1 pulse counter for LED PWM control, supporting up to 8 channels
- 1 full-speed USB OTG interface
- 1 USB serial/JTAG controller interface
- 2 MCPWM interfaces
- 1 SDIO host interface with 2 slots
- General DMA controller (GDMA) with 5 receive and 5 transmit channels
- 1 TWAI controller, compatible with ISO 11898-1 (CAN 2.0 specification)
- 2 12-bit SAR ADCs, supporting up to 20 channels
NOTE: Any GPIO can be used as PWM or ADC pin, and the numbering is consistent with GPIO. However, only up to 8 PWM channels can be enabled at the same time, so please be careful.
Board Parameter
- Size: 0.83 inches*2.01 inches
- SRAM: 512KB
- PSRAM: 8MB
- FLASH: 16MB
- WIFI IEEE: 802.11b/g/n
- Bluetooth BLE 5.0 & mesh
- Chip: ESP32-WROOM-32; Onboard CH343P USB to serial chip
- Connection: USB Type C
Shipping List
- 3 X ESP32-S3 Development Boards
- 6 X 16-PIN Headers
