Illuminated Push Button, 22Mm, Blue Schneider Electric Price O | Shop The World
From USA
NewSchneider Electric
Illuminated Push Button, 22Mm, Blue
ℹ
Products from the USA may come with an input voltage of 110V–120V, requiring a step-down transformer. Check the device wattage to select the correct power converter.
•<b>Price For:</b> Each <b>Size</b>: 22mm <b>Item</b>: Illuminated Push Button <b>Action</b>: Maintained / Momentary <b>Terminal Connection</b>: Pressure Plate <b>NEMA Rating</b>: 4, 4X, 13 <b>Standards</b>: EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, EN/IEC 60947-5-5, UL 508, CSA C22-2 n Degrees 14 <b>Color</b>: Blue <b>Voltage</b>: 24 <b>Contact Type</b>: 1NO/1NC <b>Type of Operator</b>: Round Button <b>Head Material</b>: Metal
•<b>Bezel</b>: Chrome Plated Metal <b>Lamp Module Voltage</b>: 24VAC/DC <b>Lamp Module Type</b>: Full Voltage <b>Basic Material</b>: Metal <b>Lamp Type</b>: Led <b>NEMA Contact Rating Designation</b>: A600/Q600 <b>Contact Form</b>: 1NO/1NC <b>IP Rating</b>: 65 <b>Number of Operators</b>: 1 <b>Lamp Voltage</b>: 24VAC/DC <b>Contact Rating</b>: 10A @ 600VAC <b>Country of Origin (subject to change)</b>: France
