Specification:
Condition: Brand New
Item Type: Camera Module
Material: Paperboard
Purpose: Image acquisition, color photography, simple image recognition, car tracking, automatic tracking, automatic control
Photosensitive Array: 640X480
IO Voltage: 1.7-3.0V (internal LDO power the core 1.8V)
Power Consumption: 120mH/65fpsVGA, YUV conditions
Sleep: Temperature Operation: -20℃-70℃
Stable Work: 0℃-50℃
Output Format: (10-Bit Or 8-Bit) YUV/MCbCr4: 2: 2RCGB565/555/444CGRB4: 2: 2Raw RGB Data
Optical Size: 1/4in
Field Of View: 25°
Maximum Frame Rate: 60fps VGA sensitivity 3V/(-sec)
to Noise Ratio: 50dB
Dynamic Range: 60B
Browse Mode: Line by line
Electronic Exposure: 1-510 Lines
Area: 6.0μmx6.0μm
Dark Current: 40mV/S At 60℃
Package List:
1 x Camera Module
From USA
