new | BME280 Environmental Sensor, Sense Temperature Humidity Barometric Pressure, I2C and SPI interfaces, 3.3V/5V Voltage
Brand : waveshare
new | BME280 Environmental Sensor, Sense Temperature Humidity Barometric Pressure, I2C and SPI interfaces, 3.3V/5V Voltage
Brand : waveshare
₹ 3,990.00 M.R.P :₹ 6,650.00
40% OFF
₹ 3,990.00
M.R.P :₹ 6,650.00
40% OFF
✔ In Stock
*Prices subject to change due to market. The price shown in the checkout is the guaranteed price. ₹ 3,990.00 M.R.P : ₹ 6,650.00
40% OFF
₹ 3,990.00
M.R.P : ₹ 6,650.00
40% OFF
✔ In Stock
Check Delivery Availability
Available Checking...
Quantity:
1
7 days Replacement
Secure Transaction
Free delivery
Manufacturers Warranty
Top Brand
Blue Dart Delivered
Contact For Bulk Product Enquiry
100% Secure Payments
Safe and Trusted Checkout
Note: Please be aware that products from the USA may come with an input voltage of 110V - 120V, requiring the use of an appropriate step-down transformer for compatibility. Understanding the device's wattage is essential for selecting the correct power converter.
Product Specifications
Condition
New
Asin
B0BYJMCJ4P
Category
Industrial & Scientific
Subcategory
Temperature Probes & Sensors
Leafcategory
COMPUTER_COMPONENT
Color
BME280 Sensor Module
Origin
USA
Brandname
waveshare
Weight
1
Product Details
BME280 Environmental Sensor, sensing environmental temperature, humidity, and barometric pressure.
It supports both I2C and SPI interfaces, switch to SPI via I/O setting
Onboard voltage level translator, compatible with 3.3V/5V operating voltage
Temperature sensing: -40~85°C (resolution 0.01°C, accuracy ±1°C). Humidity sensing: 0~100%RH (resolution 0.008%RH, accuracy ±3%RH, response time 1s, delay ≤2%RH). Barometric pressure sensing: 300~1100 hPa (resolution 0.18Pa, accuracy ±1hPa). Power consumption: <0.1mA@1Hz (H,P,T).
Due to its ultra-small form factor, low power consumption, high precision with stability, the BME280 Environmental Sensor is suited for applications such as environment monitoring, weather forecast, altimeter, and IoT projects, and so on.
Product Ranking
#2725 in Temperature Probes & Sensors
#828267 in Industrial & Scientific
Product Description
Overview
A tiny sensor breakout with BME280 onboard, sensing environmental temperature, humidity, and barometric pressure. It supports both I2C and SPI interfaces and also is compatible with 3.3V/5V voltage levels. Due to its ultra-small form factor, low power consumption, high precision with stability, the BME280 Environmental Sensor is suited for applications such as environment monitoring, weather forecast, altimeter, and IoT projects, and so on.
Fearture
Supports I2C (default), configurable slave address.
Supports SPI, switch to SPI via I/O setting.
Onboard voltage level translator, compatible with 3.3V/5V operating voltage.
Comes with development resources and manual (examples for Raspberry Pi/Arduino/STM32).
Specifications
Operating voltage: 3.3V/5V
Communication interface: I2C/SPI
Temperature sensing: -40~85°C (resolution 0.01°C, accuracy ±1°C)
Humidity sensing: 0~100%RH (resolution 0.008%RH, accuracy ±3%RH, response time 1s, delay ≤2%RH)
Barometric pressure sensing: 300~1100 hPa (resolution 0.18Pa, accuracy ±1hPa)
Power consumption: <0.1mA@1Hz (H,P,T)
Dimension: 27mm x 20mm
Mounting hole size: 2.0mm
Online Tutorial/Online Document: n9.cl/9cpla
PACKAGE CONTENT
BME280 Environmental Sensor x1
PH2.0 6PIN wire 20cm x1
A tiny sensor breakout with BME280 onboard, sensing environmental temperature, humidity, and barometric pressure. It supports both I2C and SPI interfaces and also is compatible with 3.3V/5V voltage levels. Due to its ultra-small form factor, low power consumption, high precision with stability, the BME280 Environmental Sensor is suited for applications such as environment monitoring, weather forecast, altimeter, and IoT projects, and so on.
Fearture
Supports I2C (default), configurable slave address.
Supports SPI, switch to SPI via I/O setting.
Onboard voltage level translator, compatible with 3.3V/5V operating voltage.
Comes with development resources and manual (examples for Raspberry Pi/Arduino/STM32).
Specifications
Operating voltage: 3.3V/5V
Communication interface: I2C/SPI
Temperature sensing: -40~85°C (resolution 0.01°C, accuracy ±1°C)
Humidity sensing: 0~100%RH (resolution 0.008%RH, accuracy ±3%RH, response time 1s, delay ≤2%RH)
Barometric pressure sensing: 300~1100 hPa (resolution 0.18Pa, accuracy ±1hPa)
Power consumption: <0.1mA@1Hz (H,P,T)
Dimension: 27mm x 20mm
Mounting hole size: 2.0mm
Online Tutorial/Online Document: n9.cl/9cpla
PACKAGE CONTENT
BME280 Environmental Sensor x1
PH2.0 6PIN wire 20cm x1
