Bewinner Microcontroller Development Board Raspberry Pi Pico 3 | Shop The World
From USA
NewBewinner
Bewinner Microcontroller Development Board for Raspberry Pi Pico 32bit Single Core Support IEEE802.11b/g/n WiFi Flexible Clock Running up to 240 MHz
ℹ
Products from the USA may come with an input voltage of 110V–120V, requiring a step-down transformer. Check the device wattage to select the correct power converter.
•IoT Applications: Support for Raspberry Pi Pico expansion board ecology to meet the development of IoT applications.
•150Mbps Transfer Rate: Support IEEE802.11b/g/n, onboard 2.4GHZ WIFI ceramic antenna, maximum 150Mbps data transfer rate. Adopt Type‑C interface, keep up with the trend of the times, no need to hesitate about the positive and negative inserts.
•Full Speed: Integrated full‑speed USB OTG, SP, 12C, UART, ADC, D/A, PWM, DVP8/16 Camera interface, LCD interface (8‑bit serial RGB/8080/6800), TWAI controller (compatible with ISO11898‑1), capacitor Type sensing GPIO, temperature sensor and RMT (TX/RX)
•High Efficiency: High Efficiency Buck Boost DC‑DC TPS63000 Power Supply IC with 1.8A Onboard Current. Stamp hole design, which can be directly welded and integrated into the bottom plate designed by the user
